Mag Audio AIR-C5T-16-BK-Wall (Zwart) inclusief muurbeugel (100 Volt)
Bestelnummer: 10959 Niet op voorraad.The compact yet powerful AIR-C5 is equipped with a 5,25” woofer and an HF driver on a rotatable horn. It is compatible with horizontal and vertical adjustable mountings and works with 70V / 100V lines as well as 16 Ohm Lo-Z connections.
Іnstallation speaker
Main features:
• 70 W nominal power
• 5,25”, 1,25" VC LF driver
• 119,5 dB Max SPL
• VESA 50x50, Safety mounting point
Frequency response (-10dB) 80 - 20000 Hz
Max SPL 119,5 dB
Sensitivity (1W/1m) 89 dB
LF Driver 5,25”, 1,25" VC
HF Driver 1” carbon fiber diaphragm, 1” VC, ND magnet
Nominal Coverage Angle (Horizontal × Vertical) 100° x 70°, rotatable horn
Nominal power 2 70 W
Impedance (transformer bypass) 16 Ohm
Transformer taps 70V 3,7 W / 7,5 W / 15 W / 30 W
Transformer taps 100V 7,5 W / 15 W / 30 W
Connections and physical data
Connectors Phoenix
Dimensions (WxHxD) 160 x 277 x 157 mm; 6,3” x 10,9” x 6,18”
Net weight 4,1 kg; 9 lbs
Shipping weight 4,9 kg; 10,8 lbs
Mounting VESA 50 x 50; Safety mounting point
Weather protection IP54 rated
Enclosure material Polycomp©, wear-resistant paint
Speaker protection Steel grill, acoustically transparent backing
Website van de fabrikant: https://mag-audio.com/products...
